非洲金礦石破碎選礦，蘇丹金礦選礦項目

蘇丹金礦選礦項目，

一、項目地質背景

    礦床特征：

    主要開采對象為第四紀沖積型砂金礦床
    礦體平均厚度3-5m，金品位1.2-3.5g/m³
    礦石真密度2.65g/cm³，松散密度1.6t/m³

    礦石特性：

    主要脈石礦物：石英（70%）、長石（15%）、云母（10%）
    金礦物形態：主要為片狀、粒狀自然金
    金粒度分布：+0.074mm占65%，0.074-0.037mm占25%

二、工藝流程設計

    碎磨系統：

原礦倉→格篩(100mm)→顎破(C6X160)→雙層振動篩→圓錐破(HPT300)→
高壓輥磨機→球磨→旋流器組(Φ350×6)

    設計破碎比i=80
    最終磨礦細度-0.074mm占90%

    重選系統：

    采用"跳汰+搖床"聯合流程
    強化微細粒回收
    設計回收率：+0.074mm金95%，-0.074mm金85%

    輔助系統：

    尾礦處理：深錐濃密機+壓濾機
    水循環率：≥85%
    電力配置：10kV高壓配電系統

三、核心設備選型

    破碎工段：

    顎式破碎機：C6X160，處理量500t/h
    圓錐破：HPT300，閉邊排料口25mm

    磨選工段：

    球磨機
    分級效率：≥85%

    環保設施：

    含氰廢水處理站（50m³/h）
    粉塵收集系統（效率＞99%）

四、技術經濟指標
項目 指標
處理能力 2000t/d
作業率 92%
金回收率 93.5%
電耗 28kWh/t
鋼耗 0.8kg/t
水耗 0.5m³/t
五、項目實施方案
    建設周期：
    設計：3個月
    施工：8個月
    調試：1個月

六、技術創新點

    采用"高壓輥磨+球磨"預選拋尾工藝，降低能耗30%
    開發了適于紅土型金礦的復合捕收劑
    應用PLC全流程自動化控制系統
    尾礦干排技術實現零排放

七、運維保障

    備件儲備：
    關鍵備件庫存率達95%

    技術服務：

    駐廠工程師團隊
    遠程診斷系統
